Temperature Controller
TC10 Series

back

TC10EM

Model: TC10EM

  • Two PID controllers
  • Universal input x 2 points, control output x 4 points, discrete input x 2 points, clamp-on current sensor input x 2 points
  • 2 universal inputs configurable to T/C, RTD, DC current or voltage independently
  • Clamp-on current sensor input enables to detect heater wire break or over current
  • Auto tuning function
  • Display
    PV display: 5 digits 7-segment green LED, 19.5 mm (.77”) height
    SP display: 5 digits 7-segment red LED, 12.5 mm (.49”) height, switchable to MV display
CE
  • Modbus

TC10NM

Model: TC10NM

  • One PID controller
  • Universal input x 1 point, control output x 4 points, discrete input x 2 points, clamp-on current sensor input x 1point
  • Universal input configurable to T/C, RTD, DC current or voltage independently
  • Clamp-on current sensor input enables to detect heater wire break or over current
  • Auto tuning function
  • Display
    PV display: 5 digits 7-segment green LED, 10.2 mm (.40”) height
    SP display: 5 digits 7-segment red LED, 8.2 mm (.32”) height, switchable to MV display
CE
  • Modbus

Front View (Model: TC10EM)

FRONT VIEW(TC10EM)

Application Examples

  • 2 Loop ON/OFF control Wire breakdown detection of heating furnace
  • Heating & Cooling PID control
